FUEL SYSTEM (EFI) 3-79
ERROR TYPE ERROR CODE POSSIBLE CAUSES
ERROR_SAFETY-SWITCH_0 49
● ROLL OVER SENSOR NOT CONNECTED
● ROLL OVER SENSOR DAMAGED
● WIRING FAULTY [Wire1 that connecting PIN31
ECU to PIN1 ROLL OVER SENSOR is at potential
≥ 5V]
ERROR_SAFETY-SWITCH_1 50
● ROLL OVER SENSOR IN ON CONDITION
(WORK)
● ROLL OVER SENSOR DAMAGED
● WIRING FAULTY [S.C. between Wire1 that
connecting PIN31 ECU to PIN1 ROLL OVER
SERNSOR and Wire2 that connecting PIN27 ECU
to PIN2 ROLL OVER SENSOR or GND]
ERROR_PICK-UP_O.C. 53
● PICK-UP NOT CONNECTED
● PICK-UP DAMAGED
ERROR_PICK-UP 54
● PICK-UP DAMAGED
● WIRING FAULTY [INVERTED WIRES]
● N° TOOTH PHONIC WHEEL NOT CORRECT
● GAP PICK UP NOT CORRECT
ERROR_IGNITION COIL 1 55
● IGNITION COIL 1 NOT CONNECTED
● IGNITION COIL 1 DAMAGED
● DISCHARGE BATTERY
● WIRING FAULTY
ERROR_IGNITION COIL 2 56
● IGNITION COIL 2 NOT CONNECTED
● IGNITION COIL 2 DAMAGED
● DISCHARGE BATTERY
● WIRING FAULTY
