Fastener
Torque
Remarks
N·m kgf·m ft·lb
Shift Drum Bearing Holder Screw 5 0.50 43in·lb L
Connecting Rod Big End Nuts see text ← ← MO
Timing Rotor Bolt 40 4.1 30
Oil Pressure Switch 15 1.5 11 SS
Gear Positioning Lever Bolt 12 1.2 106in·lb L
Shift Shaft Return Spring Pin 29 2.9 22 L
Shift Drum Cam Bolt 12 1.2 106in·lb L
Neutral Switch 15 1.5 11
Transmission Case Bolts 20 2.0 15
Neutral Switch Holder Screw 5 0.50 43in·lb L
Shift Shaft Cover Bolts 10 1.0 87in·lb L(2)
Shift Shaft Cover Screw 5 0.50 43in·lb L
Wheels/Tires
Front Axle 108 11.0 80
Front Axle Clamp Bolt 34 3.5 25
Rear Axle Nut 108 11.0 80
Final Drive
Engine Sprocket Nut 125 12.7 92 MO
Rear Axle Nut 108 11.0 80
Rear Sprocket Nuts 59 6.0 44
Speed Sensor Bolt 8 0.80 69in·lb L
Speed Sensor Bracket Bolts 10 1.0 87in·lb
Brakes
Bleed Valve 7.8 0.80 69in·lb
Brake Hose Banjo Bolts 25 2.5 18
Brake Lever Pivot Bolt 1.0 0.10 9in·lb Si
Brake Lever Pivot Bolt Locknut 5.9 0.60 52in·lb
Brake Pedal Bolt 8.8 0.90 78in·lb
Front Brake Disc Mounting Bolts 27 2.8 20 L
Front Brake Light Switch Screw 1.0 0.10 9in·lb
Front Brake Reservoir Cap Screws 1.0 0.10 9in·lb
Front Caliper Mounting Bolts 34 3.5 25
Front Master Cylinder Clamp Bolts 8.8 0.90 78in·lb S
Rear Brake Disc Mounting Bolts 27 2.8 20 L
Rear Caliper Mounting Bolts 25 2.5 18
Rear Master Cylinder Mounting Bolts 25 2.5 18
Rear Master Cylinder Push Rod Locknut 18 1.8 13
Suspension
Front Axle Clamp Bolt 34 3.5 25
Front Fork Bottom Allen Bolts 30 3.1 22 L
2-8 PERIODIC MAINTENANCE
