Fastener
Torque
Remarks
N·m kgf·m ft·lb
Front Fork Clamp Bolts (Lower) 20 2.0 15 AL
Front Fork Clamp Bolts (Upper) 20 2.0 15
Front Fork Top Plugs 25 2.5 18
Rear Shock Absorber Bolt 59 6.0 44
Rear Shock Absorber Nut 59 6.0 44
Swingarm Pivot Shaft Nut 180 — —
Steering
Front Fork Clamp Bolts (Lower) 20 2.0 15 AL
Front Fork Clamp Bolts (Upper) 20 2.0 15
Handlebar Holder Bolts 25 2.5 18 S
Left Switch Housing Screws 3.5 0.36 31 in·lb
Right Switch Housing Screws 3.5 0.36 31 in·lb
Steering Stem Head Bolt 108 11.0 80
Steering Stem Nut 20 2.0 15
Frame
Footrest Stay Bolts 34 3.5 25
Front Fender Bolts 3.9 0.40 35 in·lb
Front Fender Bracket Bolts 8.8 0.90 78 in·lb L
Front Turn Signal Light Mounting Screws 1.2 0.12 11 in·lb
Grab Rail Mounting Bolts 25 2.5 18
Lower Fairing Mounting Bolts 8.8 0.90 78 in·lb
Seat Lock Mounting Screws 1.2 0.12 11 in·lb
Sidestand Bolt 44 4.5 32
Sidestand Switch Bolt 8.8 0.90 78 in·lb L
Electrical System
Alternator Cover Bolts 10 1.0 87 in·lb
Alternator Lead Holding Plate Bolt 10 1.0 87 in·lb L
Alternator Rotor Bolt 155 15.8 114 MO
Crankshaft Position Sensor Bolts 6.0 0.60 53 in·lb
Engine Ground Cable Terminal Bolt 9.8 1.0 87 in·lb
Front Brake Light Switch Screw 1.2 0.12 11 in·lb
Front Turn Signal Light Mounting Screws 1.2 0.12 11 in·lb
Left Switch Housing Screws License 3.5 0.36 31 in·lb
Plate Light Cover Screws License 0.90 0.090 8 in·lb
Plate Light Mounting Screws Meter 1.2 0.12 11 in·lb
Neutral Switch 15 1.5 11
Oil Pressure Switch 15 1.5 11 SS
Oxygen Sensor 60 6.10 44.3
Regulator/Rectifi er Bolts 8.8 0.90 78 in·lb
Right Switch Housing Screws 3.5 0.36 31 in·lb
Sidestand Switch Bolt 8.8 0.90 78 in·lb L
Spark Plugs 15 1.5 11
