Fastener
Torque
Remarks
N·m kgf·m ft·lb
Speed Sensor Bolt 8.0 0.80 69in·lb L
Starter Motor Cable Terminal Nut 6.0 0.60 53in·lb
Starter Motor Mounting Bolts 10 1.0 87in·lb L
Stator Coil Bolts 12 1.2 106in·lb L
Timing Rotor Bolt 40 4.1 30
Coolant Temp. Sensor 12.0 1.2 106in·lb
The table below, relating tightening torque to thread diameter, lists the basic torque for the bolts and nuts.
Use this table for only the bolts and nuts which do not require a specifi c torque value. All of the values are
for use with dry solvent-cleaned threads.
Basic Torque for General Fasteners
Threads Diameter
(mm)
Torque
N·m kgf·m ft·lb
5 3.4-4.9 0.35-0.50 30-43in·lb
6 5.9-7.8 0.60-0.80 52-69in·lb
8 14-19 1.4-1.9 10.0-13.5
10 25-34 2.6-3.5 19.0-25
12 44-61 4.5-6.2 33-45
14 73-98 7.4-10.0 54-72
16 115-155 11.5-16.0 83-115
18 165-225 17.0-23.0 125-165
20 225-325 23.0-33.0 165-240
2-10 PERIODIC MAINTENANCE
