FRAME 15-9
Fenders
Front Fender Removal
● Remove:
Brake Hose Clamps [C]
Bolts [B]
● Remove the front fender [A].
Front Fender Installation
● Tighten:
Torque - Front Fender Bolts: 3.9 N·m (0.40
kgf·m, 35 in·lb)
● Install the brake hose clamps to the front fender
holes.
Flap and Rear Fender Rear Removal
● Remove:
Seat (see Seat Removal)
Seat Covers (see Seat Cover Removal)
Tail/Brake Light [B] (see Tail/Brake Light Removal
in the Electrical System chapter)
● Remove:
Bolts [A]
Tail/Brake Light nuts [A]
Rear Turn Signal Lights
● Remove:
Seat Lock Cable Lower End [A]
To Next Page
