Horn Button
Press this button, the horn will sound.
Engine Stop Switch
When the switch is at position
,
the engine shuts off.
When the switch is at position
,
the engine can be started.
Starter Switch
When the main switch is turned to ON, and the
engine stop switch is at
,
push this button to start
the engine.
Brake
Front Brake Lever
The front brake lever ②
is located on the right handlebar. Pull it
toward the handlebar to apply the front brake.
-47-
Features & Controls
