Foot Brake Pedal and Lever
WARNING
Operating the ATV with a spongy brake lever or pedal can result in loss of control, which could cause an
accident. Never operate a spongy-feeling brake lever or pedal.
-48-
Features & Controls
The foot brake pedal is located on the right side floor board of the vehicle. Push down on the pedal to apply
both the front and rear brakes. When squeezed, the lever or pedal should feel firm. A soft brake pedal would
indicate a possible fluid leak or low master cylinder fluid level, which must be corrected before riding.
Brake lever is located on the left handlebar.
Contact your dealer for proper diagnosis and repairs.
2
1
2
1
