Always test brake lever travel master cylinder fluid level before riding. When squeezed, the lever or pedal
should feel firm. Any sponginess would indicate a possible fluid leak or low master cylinder fluid level, which
must be corrected before riding. Contact your dealer for proper diagnosis and repairs.
Brake Fluid
Check front brake fluid master cylinder fliud level
before each use of the ATV.The front brake master
cylinder is located on the right handlebar.
The brake fluid reservoir is near the right passenger
footrest. The front brake fluid level can be viewed.
through an indicator window on the side of the
master cylinder.When fluid level is lower than the
①
“lower”mark,
refill with the same type of brake
fluid as necessary.
WARNING
A
n over-full master cylinder may cause brake drag or brake lock-up, which could result in serious injury or
death. Maintain brake fluid at the recommended level. Do not overfill.
-49-
