-98-
Front gear case oil measurement
1. Place the machine on a level place.
2. Remove the oil filler bolt and check the oil level .
It should be up to the brim of the hole . If the level is
low,
add sufficient oil to raise it to the specified level.
3.
Install the oil filler bolt and tighten it to the specified
torque.
NOTE
Oil filler bolt tightening torque：23 N·m
Maintenance & Lubrication
1
2
3
2
3
1
Front gear case oil change
4. Install the drain bolt and tighten it to the specified torque.
NOTE
Drain bolt tightening torque: 10 N
.
m
5. Fill the front gear case with oil.
NOTE
Periodic oil change：0.23 L
6. Install the filler bolt
and tighten it to the specified torque.
7. Check for oil leakage. If oil leakage is found, check for the cause.
2
1. Place the machine on a level place.
2. Place a container under the front gear case to catch
the oil.
3. Remove oil filler bolt and drain bolt at the bottom of front
gear case, and drain used oil.
1
1
