73
Maintenance Procedures
Air Filter
NOTE
The air filter comes installed with a moisture
catch tube. If dust or liquids collect in this
tube, clean out this tube, air filter element
and air filter housing. If a large amount of wa-
ter is present in the air filter, have your dealer
check for water entering crankcase.
Cleaning the air lter
To clean the air filter element, proceed as fol-
lows:
1. Remove the air filter cover.
2. Disengage the clamps 1 to remove the air
filter housing cover.
3. Remove the clamp bolt 4.
4. Remove the air filter #5.
5. Clean the air filter foam element, using a
high flash point cleaner. Dry out the foam
element and reinstall it.
1. Clamp 2. Air lter cover 3. Moisture catch tube
4. Bolt 5. Air filter #5 6. Foam element
1
2
3
6
5
4
