79
Front Differential Oil
To Check the Front Differential Oil
1. Place the vehicle on a level surface.
2. Remove the fill plug #2 and check the oil
level. Maintain the oil level even with the
bottom thread of the fill plug hole.
3. Reinstall the fill plug and torque it to specifi-
cation.
NOTE
Fill plug tightening torque: 25 N·m
To Change the Front Differential Oil
1. Place the vehicle on a level surface.
2. Place an oil pan under the front differential
to collect the used oil.
3. Remove the fill plug and drain plug. Allow
the oil to drain completely.
4. Reinstall the fill plug #2 and torque it to
specification.
NOTE
Drain plug tightening torque: 25 N·m
5. Add recommended oil to proper level.
NOTE
* Oil capacity at periodic maintenance: 0.28L
* Oil capacity in total: 0.33L
6. Install the fill plug #2 and torque to specifi-
cation.
7. Check for oil leaks. If oil leakage is present,
troubleshoot the problem.
CAUTION
No foreign material enters the rear final drive.
