54
CHAFFOLINK
3. TECHNICAL FEATURES
GATEWAY
Conformity LVD: 2006/95/EC
EMC: 2004/108/EC
R&TTE: 1999/05/EC
ROHS: 2011/65/EU
Standards LVD: EN 60950-1
EMC: ETSI EN 301 489-17 ETSI EN 301 489-1
R&TTE: ETSI EN 300 328
ROHS: EN50581
Product installation On the wall or on the product’s chassis,
when possible
Operating temperature -10°C ÷ 60°C
Storage temperature -20°C ÷ 70°C
Power supply 0-24V
Powered by Ebus2 Cha oteaux Bridge-
Net®
Electrical absorption Max 40 mA ÷ Max 0,7 W
Total consumption (BUS devices) Max 120 mA ÷ Max 3 W
Weight 0,1 kg
International Protection Marking IP 20
120 mm 23,3 mm
80 mm
WEBBUS A.P.
Gateway
Use the following link to rapidly download from the Internet the interface instructions
manual for the Expert Control system, already featured on certain installation schemes:
http://www.Cha oteaux.com
3
2
1
Legend:
1. BridgeNet Bus LED
2. Internet Connection LED
3. WI Fi confi guration button
