21
Chapter 7 Device characteristic
Physical characteristics
Size 250.8mm x 152mm x 15mm/ 9.87 x 5.98 x 0.59in
Weight 700g/24.7oz
Display 8'' IPS LTPS 1920x1200
Touch panel Corning Gorilla Glass, multi-touch panel, gloves
and wet hands supported
Battery Main battery: Li-ion, rechargeable, 8000mAh
Expansion Supports up to 32 GB Micro SD card
Expansion Slot 1 slot for SIM card, 1 slot for SIM or TF card
Audio speaker, 2 microphones, voice call
Camera 13MP autofocus camera with flashlight
Performance
CPU 2.0GHz MSM8953
OS Android 7.1
RAM 2GB RAM
Communication
Interface
USB 3.0 Type-C, OTG
ROM 16GB
Max. expansion Supports up to 32 GB Micro SD card
User environment
Operating temp.
-20℃to 50℃
Storage Temp.
-40℃ to 70℃
Humidity 5%RH - 95%RH non condensing
Sealing IP65, IEC sealing standard
Drop
specification
Multiple 1.2m/3.9ft drops to concrete across the
operating temperature range
