12
2. Spark plug (Fig.H)
1) Once the engine has cooled, remove
the spark plug using the socket spanner
supplied.
2) Clean the plug with a wire brush.
3) Using a feeler gauge, set the gap to
0.75mm.
4) Install the spark plug carefully by
hand, to avoid cross-threading.
5) After the spark plug is seated, tighten
with spanner to compress the washer.
3. Air fi lter (Fig.I,I1)
Unclip the air fi lter cover and remove
the sponge fi lter element. To avoid
objects falling into the air tank, replace
the air fi lter cover. Wash the fi lter
element in warm soap water, rinse and
allow to dry naturally.
Warning! Never run the engine
without the air fi lter element
installed.
4. Changing the oil
Tilt the lawnmower towards the oil filler,
have a container ready to catch the oil and
remove the dipstick. Once the oil has
been emptied, replace the dipstick and
wipe clean any spillages.
Refi ll with SAE30 oil. When the dipstick is
rested on the fi ller pipe (i.e. not screwed
in place), the oil level must be between
the min and max marks on the dipstick.
See “Filling with Engine Oil’’. Do not
overfi ll.
Start the engine and allow it run briefl y.
Stop the engine, wait one minute and
check the oil level. Top up if necessary.
5. Blade Sharpening (Fig J,K,L, )
Fig J
Fig K
ORIGINAL INSTRUCTIONS
