PARTS LIST
INSTALLATION
This unit can easily be moved from one room to another. While moving
the unit please note that it must always be kept upright and then
placed on an even surface.
Remove any packaging - keeping the air cooler in a vertical position.
Make sure all parts are present and unit is assembled correctly -
including the castor wheels (these need to be pushed into place on the
base of the unit)
Front Foot-wheel
Rear Foot-wheel
Foot-Wheel Installation
Fig.2
Ice box
Pre-filter
Honeycomb filter
Honeycomb filter frame
Water tank
Control panel
Handle
Air flow outlet
Water tank cover
Water tank top cover
Filter net
Wheel
Water window
