Introduction
01-16 79033093 D Rev.
FIG. 29: Cab Serial Number. Plate is located inside cab,
below inching clutch control.
Cab Serial Number: ____________________________
FIG. 30: Operators Seat Serial Number. Tag (1) is
located on rear of operator’s seat.
Seat Serial Number: ___________________________
FIG. 31: Track Belt Serial Number. The serial number is
located on edge of each belt.
Left Belt Serial Number: _________________________
Right Belt Serial Number: ________________________
FIG. 32: Serial Number for differential and for axles. The
plate is located beneath rock shaft for three-point hitch.
Differential and Axles Serial Number: _______________
FIG. 29
FIG. 30
FIG. 31
FIG. 32
