Challenger TG8300 - Safety and Service Sign Locations - Cab

SAFETY
A-26 549687D1 E Rev
FIG. 53: (12) Hydraulic Oil Level. Located on hydraulic
oil tank next to level window.
SAFETY AND SERVICE SIGN
LOCATIONS - CAB
FIG. 54: Cab shown with glass and other components
removed for ease in viewing interior.
See following pages for identification.
FIG. 55: (13) Primary Fresh Air Filter. Located under
front edge of roof in front of windshield.
FIG. 53
R101315006
FIG. 54
R101315007
13
14
15
16
17
18
22
21
19
23
24
25
26
20
20
27
FIG. 55
237270
