Cabinet Stacking
Remove drawers, see step 3. Punch out the knockouts on the top
and bottom of the cabinet using a punch and hammer, See Fig. 7.
Align cabinets so that the front and top are flush. Use hardware
shown in Fig. 6. Install all drawers.
5.
Installation
THIS DOCUMENT IS CONFIDENTIAL AND PROPRIETARY
Fig. 7
Ganging Hardware Kit
Part #7001257
Fig. 6
X 4 X 8 X 4
PART NO. 1000581
