Replacement Parts
(1) 41A5644 Trolley with Chain/Cable Assy.
(3 piece rail)
041A0516-1 Trolley with Chain/Cable Assy
(1 piece rail)
(2) 041A6342 Head Only
(3) 041A5643-4 Hardware Bag
(4) 41B0668 Door Bracket
(5) 41C0669 Header Bracket
(6) 001A5644 Inner Trolley
(7) 41C5620 Outer Trolley
(8) 41C0521-1 Limit Switch (3 piece rail)
041A0521-2 Limit Switch (1 piece rail)
(9) 002D0838 1 piece rail
(10) 41A5675 Rail Hardware
(11) 41A5676 Rail Sections
041A5626 Logic Board
041A0157-1 Transformer
Specifications
Input Voltage . . . . . . . . . .230 VAC 50/60 Hz
Max. Pull force . . . . . . . .600N
Rated Power Input . . . . .85 Watts
Rated Load . . . . . . . . . . .3.0 Nm
Standby Power . . . . . . . .9 Watts
Max. Door Weight . . . . . .60kg
Motor
Type . . . . . . . . . . . . . . . .63:1 Worm Gear Reduction
Volts . . . . . . . . . . . . . . . .24VDC
Drive Mechanism
Length of Travel . . . . . . .2.8M
Travel Rate . . . . . . . . . . .8cm/sec
Lamp . . . . . . . . . . . . . . . .24V 21 Watts
Safety
Electronic . . . . . . . . . . . .Auto-Force Adjustment
Electrical . . . . . . . . . . . . .Thermal Fuse in Transformer
Limit Adjustment . . . . . . .Manual
Dimension
Length (Overall) . . . . . . .3.3m
Headroom Required . . . .30mm
Hanging Weight . . . . . . . .10kg
Receiver Code Registers
Billion Code . . . . . . . . . . .12
Dip Switch . . . . . . . . . . . .1
Keypad . . . . . . . . . . . . . .1
Operating Frequency . . .433.92MHz
24
Accessories
(1) Model 4335EML 3-Function Mini Remote Control
(2) Model 770EML The Protector System
(3) Model 747EML Wireless Keyless Entry Keypad
(4) Model 845EML Multi-Function Door Control Panel
(5) Model 75EML Lighted Door Control Button
(6) Model 760EML Outside Keylock
(7) Model 1702EML Outside Quick Release
23
Wiring the Multi-Function Door Control Panel
and the Lighted Door Control Button (Optional)
Locate any Wall Mounted Door Control where the garage door
is visible, away from door and door hardware, at a minimum
height of 1.5m. fasten the child warning label on the wall near
the Door Control.
There are 2 screw terminals (1) on the back of the Door Control
(2). Strip about 6mm of insulation from bell wire (4). Separate wires
enough to connect the white/red wire to terminal screw 1 and the
white wire to terminal screw (1).
Lighted Door Control Button: Fasten to an inside garage wall
with sheet metal screws (3) provided with Lighted Push Button.
Drill 4mm holes and use anchors (6) if installing into drywall or
concrete. A convenient place is beside the service door and out of
reach of children.
Multifunction Door Control: Insert a small flat head screwdriver
into the top of the Wall Control (10), gently pry the cover off.
Fasten to an inside garage wall with sheet metal screws (8) as
follows:
• Install bottom screw, allowing 3mm to protrude from the wall.
• Position bottom of door control over screw head and adjust for
snug fit.
• Install top screw with care to avoid cracking plastic housing. Do
not over tighten.
• Replace cover by inserting bottom tabs (9) and snapping into
place. To remove cover after mounting, gently pry at top with
paper clip or small flat head screwdriver.
Run the bell wire up the wall and across the ceiling to the garage
door opener. Use insulated staples (5) to secure wire.
The opener Quick-Connect Terminals (7) are located in the recess
next to the learn button on the left side panel. Insert bell wire into
holes in the Quick Connect Terminals as follows: Red/White to
Red and White to White.
22
114A3269B Printed in China
5-GB
