2
CH C
CH D
VIDEO AUDIO L AUDIO R
CH A
CH B
VIDEO AUDIO L AUDIO R
OUTPUT
600mA
15VDC
POWER
The ChannelPlus 5400 Series are digitally-tuned video modulators that convert any
baseband video and audio signal to a user-selected UHF, or Ultraband CATV. An
internal quartz crystal reference oscillator and PLL circuitry ensure drift-free
performance. The user selects the output frequency (channel) using the "select"
button to choose which modulator and the "program" button to enter the number of
the desired channel. Any TV connected to the output via coax can receive the
signals, when the TV is tuned to the proper channel.
5425 2 channel modulator
5435 3 channel modulator
5445 4 channel modulator
Models available:
®
model 5445 quad digital modulator
pll frequency control
D
C
BA
program
select
Controls and Connections - Model 5445 shown
RF output
Select button chooses
the modulator.
Program button enters
the channel number
Modulator LEDs show which
modulator is selected
Video inputs
Power supply
15VDC 300mA (5425 & 5435)
15VDC 600mA (5445 only)
Audio inputs: Right and Left
Terminating jumpers (remove for hi-Z)
Option:
To connect the video and audio to a local monitor, use RCA type ‘Y’ adaptors and
remove the ’LOOP’ jumper for this channel.
The model 5435 has built in loop through connectors on the “A” channel, so it
does not require the use of a ‘Y’ adaptor.
VIDEO AUDIO LAUDIO R
Remove jumper for Hi-Z
(See manual)
AB
C
D
C
ADB
Cable HRC and IRC considerations
Note
Most cable services use IRC frequency assignments. This is the default for
the ChannelPlus modulators. However, if the cable service
uses HRC or the TV appears to search for the "house channels," the
modulator can be reprogrammed to use HRC assignments by entering the
number “ 98”. Set to IRC by entering a “99”. Both of these settings are only
used for setting HRC/IRC. : This setting can be entered on any
modulator channel, A, B, C, or D, and affects all channel assignments for
that unit. Cable channels must either be IRC or HRC.
5400 series
all all
Changing modulation standards
7
Specifications: typical @ 25 C ± 5 C
OO
5400 Series modulators
RF output
Power supply
Physical
performance
Video
Inputs
65-125
(excluding 95-99)
14-64
channel ranges
model number
signal/noise 55 dB
-60 dBC
5 watts
3.5 watts
7 watts
+25 dBmV (85dBµV)
105-125 VAC
-45dBC @ 12MHz
300mA
300mA 600mA
15 VDC
differential phase
<4º
differential gain
L & R inputs combined for monaural
4%
audio
1 V rms @ 47k
video
UHF
544554355425
350-076
350-076
350-079
CATVstandard
1Vp-p@75
output level
input power
IM distortion
power consumption
alternate channel
output voltage
output current
weight 1.19 kg (2 lbs 10 oz)
depth 14.1 cm (5.5 in)
width 20.0 cm (7.9 in)
height 3.8 cm (1.5 in)
Mounting hole template
To hang with connectors on the side
To hang with connectors on the bottom or top
