Chapin Spot Sprayer Operator’s Manual - English
2E
CONTENTS- NOT TO SCALE
H-1
Phillips Head Screw
C-3
External Bypass
H-3
Worm Gear Clamp
H-7
Lead Wire Assembly
H-5
Drain Cap w/ Lanyard
H-6
Loop Clamp
C-1
Wand Assembly
H-2
Phillips Head
Screw
H-4
Wand Clamp
SPRAYER HARDWARE
SPRAYER COMPONENTS
C-2
Pump
C-4
Flow Director Valve
NOTE: not all components shown may be needed on your model.
