Chapin 97902 - Spray Pattern and Nozzle Adjustments

12E
SPRAY PATTERN ADJUSTMENT FOR PUSH SPRAYING
Spray left
Spray Right
Easily spray to left or right with positionable wand holder built right into the cap.
ADJUST NOZZLE HEIGHT
Loosen the cam lock handle to adjust the height
of the nozzle bar.
SWITCH FROM BOOM SPRAY TO SPOT SPRAY
Turn switch to the desired spray option.
BOOM
SPOT
