Char-Broil Alpine - Hardware Details; Assembly Tools Required

Tools needed for assembly: adjustable wrench, Phillips screwdriver.
HARDWARE
Hardware is shown actual size. You may have spare hardware after assembly is complete.
#10-24
Flange
Qty. 18
Nut
#10-24x1/2”
Machine Screw
Qty. 10
#10-24x1/2”
Hex-Head Machine Screw
Qty. 8
#10-24x3/8”
Machine Screw
Qty. 8
#10-24
Hex-Keps Nut
Qty. 8
#10x1/2”
Self-Tapping Screw
Qty. 1
