Char-Broil Performance 463341021 - Page 45

CHARBROIL.COM
Page 45
ASSEMBLY / ASSEMBLAGE / ASAMBLEA
14
15
2ND
1ST
1ST
#14
#15
#14
#15
2ND
Remove screws
Enlevez les vis
Retire los tornillos
Secure using screws that were removed from sideburner valve bracket.
Fixez le tout au moyen des vis enlevées du support de valve du brûleur latéral.
Fíjelo con los tornillos que retiró del soporte de la válvula del quemador lateral.
#16
#57
#18
