3
4
This step requires two people
to lift and position grill head
onto cart.
Carefully lower the grill
head onto the cart, aligning slots at
bottom of grill head with posts on
cart side panels. Make sure the
regulator hose is hanging outside
the cart. Grill head must face open
side of cart.
Place lower back panel between side
panels at rear of bottom shelf. Secure
lower back panel to side panels using four
1/4-20x1/2” screws, 7mm lock washers,
and 7mm flat washers on each side.
14
Lower back panel
1/4-20x1/2” screw
7mm lock washer
7mm flat washer
Regulator hose
Grill head
