CHARGETRONIX TP-EVPD-160kW - Page 6

6
Product Number
TP5-160-480
HPC-160-480
Input Voltage
480V (3P + N + PE), 60Hz
Output Voltage
150–1000 VDC
Max Output Current
Up to 200A per connector
Up to 400A per connector
FLA || Breaker Rating
215A || 300A
Power Factor
>0.98
Efficiency
>94% at nominal output power
Connector Options
CCS1 and CCS1
CCS1 and CHAdeMO
CCS1
CCS1 and CCS1
CCS and CHAdeMO
CHAdeMO Cable
125A (Standard) or 200A
CCS Cable
200A
400A Liquid Cooled
Charging Protocol
Standards
Mode 4, IEC-61851, ISO-15118, DIN 70121 || Mode 4,CHAdeMO 0.9,1.0
Cycle Mode
1 x 160kW (Max: 200A)
1 x 160kW (Max: 400A)
Parallel Mode
2 x 80kW
2 x 80kW
Connector cable length
CCS – 16ft (5m)
CHAdeMO – 16ft (5m)
CCS –13ft (4m)
CHAdeMO – 16ft (5m)
Cable Management
Included
Included
Weight
880 lbs. (400 kg)
1221 lbs. (550 kg)
Dimensions (L x D x H)
29.5” x 26.5’’ x 73’’
Insulation (input – output)
>2.5 kV
Ingress Protection
NEMA 3S (IP54), IK10
Operating Temperature
-22°F to 131°F (-30°C to 55°C)
Altitude
< 6600ft (2000m)
Working || Storage Humidity
≤ 95% RH || ≤ 99% RH (Non-condensing)
Display
10’’ LCD touch screen
Communication || Protocol
Ethernet, 4G/WiFi || OCPP 1.6J
Access Control
RFID: ISO/IEC 14443A/B | Credit Card Reader (Optional)
Metering
DC kWh meter per each connector
Power Electronics Cooling
Air cooling fans
Electrical Safety: GFCI
RCD 20 mA Type A
Electrical Safety: Surge
Protection
20 kA
Electrical Safety General
Over Voltage, Under Voltage, Over Current, Missing Ground
Electrical Safety: Output
Short
Output power disabled when output is short circuited
Electrical Safety
Temperature
Temperature Sensors @ Charge Coupler and Power Electronics
Emergency Stop
Disables output power with emergency stop button
Regulatory Compliance
UL-2202 || EMC: EN 61000-6-1:2007, EN 61000-6-
3:2007/A1:2011/AC:2012
