Fig.3.FlameEffectBulbReplacement
1)LiftBulbfromclip
2)RemoveBulbfromHolder
Holder
Sleeve
Clip
Bulb
Sleeve
removethecoals.LiftofftheFrontFence.Liftoutthe
fibreglasscoaleffect.Lifttheright-handendofthe
bulbandcoveroutofitsclip,seeFig.3,thenunplug
thebulb,movingittowardstheright.Slidethecover
offanddiscardtheoldbulb.Slidetheoldcoveronto
thenew
bulbandinsertthebulbbaseintotheholder
ontheleft.Ensurethatthebulbispushedfully
home,thenlowertheright-handendandpressit
intotheclip.Replacethefibreglasscoaleffect,with
therearedgepassingjustunderthePerspex.Re-fit
thefrontfenceandreplacethecoals.
Page5
OLXV5.205.04
