CHART MVE 616 - Page 128

MVE Biological Systems
TEC 3000 Operating and Maintenance Freezer Manual
13289499 Rev H • 127
Part Number: 11864171 includes the following in Table 1. Please reference Figure 1.
Reference Table 1 and 2, and Figure 1 and 2 for installation instructions if purchasing a new
Backup Battery Assembly.
Table 1
ITEM #
PART NUMBER
DESCRIPTION
QTY
U/M
1
14122210
BATTERY BACKUP ENCLOSURE
1
EA
2
14122228
BATTERY BACKUP ENCLOSURE COVER
1
EA
3
10718155
BATTERY 12 VDC 7 AMP-HR
2
EA
4
10560431
CABLE TIE 15"L X 5/16"W
2
EA
5
10491780
PHILLIPS HEAD SCREW #8-32X3/8"
4
EA
6
4613809
CONNECTOR SPADE FEMALE .187W
4
EA
7
20535153
TAPE NEOPRENE CLOSED CELL
0.02
RL
8
11858475
FUSE HOLDER IN-LINE 5MMX20MM
1
EA
9*
11858467
FUSE 4A 250V
2
EA
10
14037103
POWER CORD 18GA
3
FT
11
14061533
STRAIN RELIEF 5/8 HOLE
1
EA
12
13284962
CONNECTOR HOUSING 2 PIN FEMALE
1
EA
13
15064293
SPLICE 22-18GA CRIMP ON SEALED
2
EA
14
10692830
WIRE CU 18GA TINNED YELLOW
1
FT
16**
2913851
PHILLIPS HEAD SCREW SS #10-32X1/4"LG
4
EA
16**
2915841
PHILLIPS HEAD SCREW SS #10-32X1/2"LG
4
EA
17**
2914931
WASHER FLAT SS 13/64IDX7/16"OD
4
EA
18**
2911071
WASHER SPLIT SS #10 18-8
4
EA
*Fuses item 9 should be taped to battery when battery enclosure cover is removed. One fuse is a
spare to remain taped inside the enclosure after installation.
**Mounting hardware items 16, 17 and 18 should be in a plastic bag tied to the cable.
