14 ASSEMBLY Ceramic Cooktops
assembly
min.
25mm
min.
25mm
min. 20mm
min. 20mm
Installation above cupboards or drawers
Under hob access must be restricted by the addition of a
board mounted at least 20mm from underside of hob.
Installation above cupboards or drawers
Under hob access must be mounted at least 20mm from
top of appliance.
