UC-PS18 USER MANUAL 8
Four, (4)
mounting holes
3-1/4”
1-7/8”
RH filler notched
at back corner to
allow plug clrearance
Four, (4)
mounting holes
1
3-1/2”
wide filler
along front
and sides
8-1/4”
2-1/2”
2-3/8”
2
Cabinet with recessed bottom
30” cabinet (typical)
Cabinet with
recessed bottom
10-1/2” x 3-3/4” hole
CL
15”
2-3/8”
1-1/4”
2”
1” hole
Four, (4)
mounting holes
3-1/4”
1-7/8”
Four, (4)
mounting holes
1
8-1/4”
2-1/2”
2-3/8”
2
Cabinet with flush bottom
30” cabinet (typical)
Cabinet with
flush bottom
10-1/2” x 3-3/4” hole
CL
15”
2-3/8”
1-1/4”
2”
1” hole
3. Rectangular Horizontal Adapter
