ChemInstruments RDS-100 User Manual

3. Visibly check to see that the Die is resting on the Bottom Roll (see KEY
COMPONENTS).
4. Insert a sample of the material to be cut.
5. Turn the handle to rotate the Die and cut the sample material (see
OPERATION).
6. Inspect the material for even cutting across the entire width.
7. If the material is not cut properly, adjust the depth of cut by turning both Die
Pressure Screws 1/8 rotation clockwise. Take care to do this evenly in order to
maintain equal pressure across the full width of the Die.
8. If the center of the material is not being cut, but the outside edges are being cut,
the Die has too much pressure. Repeat the procedure starting at step 1.
9. Repeat steps 4 – 8 until optimal cutting has been achieved.
WARNING: Be careful not to apply too much pressure to the Die. Too
much pressure will result in the Die bowing, which may prevent the Die
from cutting evenly.
