Training Center of After-Sales Department Chery International
6. Anti-theft alarm and locking system
112
3. Function description
Warning management of PEPS vehicle (CVT comfort/luxury, MT comfort/luxury):
Anti-theft failure mode:
At IGN SW-OFF, if any door is not closed, operate PKE or PE to lock door, and BCM will receive
“order information=1(lock)，Information Source=1(SMART) or 2(RKE)”) and turn on the turn
signal lamp for 500ms; 1.5s later, the turn signal lamp will be lit for another 500ms. The door will
be locked and 500ms, unlocked, with the horn silent.
At IGN SW-OFF, if the engine hood or trunk lid is not closed, operate PKE or PE to lock it, and
BCM will receive “order information=1(lock)，Information Source=1(SMART) or 2(RKE)”) and
light the turn signal lamp for 500ms; 1.5s later, the turn signal lamp will be lit for another 500ms.
The engine hood or trunk lid will be locked with the horn silent.
