Chery Tiggo 5 T21 - Page 13

Training Center of After-Sales Department Chery International
1. Vehicle communication system
13
2. T21 communication bus
– T21 body CAN bus
High-speed communication network
ICM
CAN-H
CAN-L
CLM TPM
Diagnose
interface
RRM
BCM
1-28
1-27
10
2
CAM
 Equipment of CLM double-zone automatic air conditioner;
 TPM and CAM are reserved modules now.
