Training Center of After-Sales Department Chery International
10. External lighting system
149
3. Function description – Follow Me Home
Hazard lamp
switch
The hazard lamp is independent of the key position. If hazard lamp switch is
turned on, left and right turn signal lamps will flash at the frequency of 75
flashes/minute. The hazard lamp switch is a micro switch.
With the hazard lamp activated, the instrument receives CAN signal (LH Turn
Signal Sts=1 or RH Turn Signal Sts=1) and turns on the indicator lamp at the
same flashing frequency with external turn signal lamp, accompanied with sound
prompt.
Function description of external lighting
Parking lamp
With the key at ACC or ON, turn the multi-function switch to parking lamp
position, and BCM will turn on parking lamp.
With the key at ON, turn the multi-function switch to low beam position, and BCM
will turn on parking lamp.
With the key at OFF, turn the multi-function switch to parking lamp switch, and
the parking lamp will be lit.
With the parking lamp lit, body CAN signal Parking Light Sts=1 will be sent to the
instrument to illuminate the parking lamp indicator.
