10. External lighting system
155
3. Function description – Follow Me Home
Function description of external lighting
Parking lamp
When the parking lamp output terminal is shorted to GND, BCM drive chip will
cut off the output:
The parking lamp control circuit supports following fault code strategy:
DTC
DTC parameter
Description Type of fault
HIGH MIDDLE LOW
B1003-11 90 03 11
Left parking lamp circuit
Shorted to GND
B1003-13 90 03 13 Output open circuit
B1003-19 90 03 19 Exceedance of output limit
B1004-11 90 04 11
Right parking lamp
circuit
Shorted to GND
B1004-13 90 04 13 Output open circuit
B1004-19 90 04 19 Exceedance of output limit
