Chery Tiggo 5 T21 - Page 175

Training Center of After-Sales Department Chery International
12. Instrument cluster
175
2. Function description
Instrument backlight control and backlight illumination logic
Status
Input Display
Power
mode
Pin 12
backlight,
PWM signal
LCD backlight Pointer, dial backlight
1 D1(ON)
ON
The brightness is adjustable. The max. brightness of LCD
screen backlight is 25±7cd/ m
2
(night mode).
2 D2 (ACC)
3 D3 (OFF)
4 D1 (ON)
OFF
The brightness is unadjustable, and the brightness is at its
maximum value (daytime mode of LCD)
5 D2 (ACC)
The brightness is unadjustable, and the
brightness is at its max value (daytime mode)
OFF
6 D3 (OFF)
OFF
(LCD screen backlight is
not activated)
Max. brightness
(LCD screen
backlight is
activated)
7 D4 / OFF
