Training Center of After-Sales Department Chery International
12. Instrument cluster
203
2. Function description
Driving range
– Display method
• DTE (Data terminal equipment) has a display precision of 1km; namely, DTE is a
multiple of 1km.
– Refreshing time
• Refreshed every 10s; each 1km the car travels, DTE will carry out a calculation.
• Maintenance reminder
– Maintenance distance zeroing
The driving range signal comes from BCM_BSM_4_G, BCM_ESM_4_G, Pin27
frequency signal and pin 21 fuel sensor resistance signal input. The driving range
display is valid in D1 mode.
The maintenance distance can’t be lost due to power interruption. It can be zeroed by
either of two ways:
1) Manual clearance: In D2/D3 mode, press and hold SET, and then KEY ON; namely,
maintain the instrument for 5s in D1 mode;
2) Via the diagnostic apparatus.
