3. Cruise control system
57
– IGN-ON, press ON/OFF switch, and BCM will continuously send CAN signal “Main
switch=1” to Power CAN. Press cruise ON/OFF switch again and “Main switch=0”.
When IGN SW just turns to ON position, the initial cruise mode is off, CAN signal “Main
switch=0”.
– IGN-ON, press and hold “RES/+”, and BCM will send CAN signal “RES/+ =1” to Power
CAN; release the switch, and BCM will send CAN signal “RES/+=0” to Power CAN.
– IGN-ON, press and hold “SET /-”, and BCM will send CAN signal “SET /- =1”to Power
CAN; release the switch, and BCM will send CAN signal “SET /-=0”to Power CAN.
Working principle of cruise control system
2. Working principle
