Training Center of After-Sales Department Chery International
4. BCM
65
3. Function description
3 Turning lamp
When key at ON, if left turn lamp switch is activated, left turn lamp will on.
When key at ON, if right turn lamp switch is activated, right turn lamp will on.
4
Hazard
warning lamp
When hazard warning lamp switch is activated, all turning lamps will be lit at
the same time.
Press hazard warning lamp switch and hazard warning lamp will be lit. Press
the switch again, the lamps will be off.
The hazard warning lamp is independent of the IGN SW status.
If hazard warning lamp works, indicator lamp of hazard warning will be lit.
5
Diagnosis of
turning lamp
and hazard
warning lamp
If one of turning lamp is damaged, turn on the turning lamp on this side, the
turning lamps on this side and the corresponding indicator on instrument
cluster will flash at double normal frequency. For the other side turning lamp
works normal if it is no trouble.
If one of turning lamp is damaged, active the hazard warning lamp, turning
lamps and the indicator lamp of hazard warning on instrument cluster will
flash at double normal frequency, the indicator lamp of hazard warning lamp
switch will also flash at double normal frequency.
