5. Window & anti-pinch sunroof system
87
Description of fault protection function
The window lifter motor is controlled by relay in BCM:
When BCM detects upper/lower limit position of the glass, BCM will stop driving window lifter motor
(the stalling time is 400ms±50ms).
After 8s of BCM receives glass lifting signal, if the glass is not raised or lowered to its limit position,
the lifter motor will stop working.
Where a certain external resistance is detected, BCM will stop the relay working to protect the circuit
and avoid any pinch.
DTC designation
DTC parameter
Description Fault type
HIGH MIDDLE LOW
B100C-13 90 0C 13 FL window glass up Output open circuit
B100C-71 90 0C 71 Relay seized
B100D-13 90 0D 13 FL window glass down Output open circuit
B100D-71 90 0D 71
B100E-13 90 0E 13 FR window glass up Output open circuit
B100E-71 90 0E 71 Relay seized
B100F-13 90 0F 13 FR window glass down Output open circuit
B100F-71 90 0F 71 Relay seized
B1010-13 90 10 13 RL window glass up Output open circuit
B1010-71 90 10 71 Relay seized
B1011-13 90 11 13 RL window glass down Output open circuit
B1011-71 90 11 71 Relay seized
B1012-13 90 12 13 RR window glass up Output open circuit
B1012-71 90 12 71 Relay seized
B1013-13 90 13 13 RR window glass down Output open circuit
B1013-71 90 13 71 Relay seized
2. Operation of window regulator system (without anti-pinch function)
