Fault code strategy (with anti-pinch function)
DTC
DTC parameter
Description Fault type
HIGH MIDDLE LOW
B1028-09 90 28 09 FL anti-pinch module Element fault
B1029-09 90 29 09 FL door local switch seized Element fault
B102A-09 90 2A 09 FL window lifter motor Element fault
B102B-16 90 2B 16
FL window lifter motor voltage
Low voltage
B102B-17 90 2B 17 High voltage
B102C-98 90 2C 98 FL window lifter motor temperature protection Element or system temperature too high
B102D-09 90 2D 09 FR anti-pinch module Element fault
B102E-09 90 2E 09 FR door local switch seized Element fault
B102F-09 90 2F 09 FR window lifter motor Element fault
B1030-16 90 30 16
FR window lifter motor voltage
Low voltage
B1030-17 90 30 17 High voltage
B1031-98 90 31 98 FR window lifter motor temperature protection Element or system temperature too high
B1032-09 90 32 09 RL anti-pinch module Element fault
B1033-09 90 33 09 RL door local switch seized Element fault
B1034-09 90 34 09 RL window lifter motor Element fault
B1035-16 90 35 16
RL window lifter motor voltage
Low voltage
B1035-17 90 35 17 High voltage
B1036-98 90 36 98 RL window lifter motor temperature protection Element or system temperature too high
B1037-09 90 37 09 RR anti-pinch module Element fault
B1038-09 90 38 09 RR door local switch seized Element fault
B1039-09 90 39 09 RR window lifter motor Element fault
B103A-16 90 3A 16
RR window lifter motor voltage
Low voltage
B103A-17 90 3A 17 High voltage
B103B-98 90 3B 98 RR window lifter motor temperature protection Element or system temperature too high
