Chesterton Connect - Install Sensor; NPT Thread Preparation; Attach Connector and Status Indicators; M12 Connector Installation

1
Install Sensor
Apply thread sealant tape on the 1/4" NPT
threads. Install the process sensor NPT plug.
2
Attach Connector
Attach the M12 pin connector to the unit.
Green = Ready for Connection
Blue = Connected
Red = Alert
