6-18
Engine Air Cleaner/Filter
“VORTEC” 4300 V6 Engine
2200 L4 Engine
1. To remove either air cleaner, remove the fasteners
that hold the cover on.
2. Remove the cover and lift out the air filter.
3. Insert a new air filter, then replace the air cleaner cover.
4. Tighten the fasteners to hold the cover in place.
Refer to the Maintenance Schedule to determine when to
replace the air filter. See “Scheduled Maintenance
Services” in the Index.
