DISPLAY (ITEMS)
(INSTRUMENT CLUSTER)
**P-80 (Owners)
CHANGE (Main Display)
1- Be in Particular DRIVE MODE
First (My Mode-Z Mode, etc.)
2- PUSH- (Right Arrow)
3- OPTIONS- (Display Design)
PUSH- (Center Button)
4- DISPLAY DESIGN- (Displays)
PUSH- (Center Button)
5- DISPLAY- PUSH- (Right Arrow)
to see choices. PUSH (Center
Button) to select Display want
CHANGE (Left Cluster Tiles)
1- OPTIONS- (Info Tile Selection)
PUSH- (Center Button)
2- INFO TILE SELECTION- Scroll
through the tiles, Select Tile by
PUSH- (Center Button).
NOTE-
Dark Box indicates what is
currently on Cluster Tile.
To Delete a Tile- Click on it.
PUSH (Center Button)
NOTE-
Use (RIGHT STEERING WHEEL CONTROLS) To Scroll Displays.
Press (L-R ARROWS) to Access Applications
Roll (Thumbwheel-Up & Down) For List Of Available Features.
Press (Thumbwheel) To (SELECT)
PERFORMANCE-
G-FORCE- Gives the driver an indication of the vehicle
performance in cornering. The G-force gauge will show as an
info tile on the left side of the cluster, if selected.
FRICTION BUBBLE- A four quadrant visual display, indicative of
the four corners of the car, with a “bubble” showing where the
most inertia is being exerted on the vehicle..
PERFORMANCE TIMER-
o Enter Setup Menu- Press the thumbwheel -
o Select Set Start Speed- Scroll to desired Start Speed,
and then press the thumbwheel to save it.
o To change the End Speed- scroll to End Speed and use
the thumbwheel to scroll to desired End Speed. Press
the thumbwheel to save it.
o On the next acceleration, the performance timer will
record the time.
o Pressing the thumbwheel while the timer is running
will cancel the timer if done before reaching the End
Speed.
LAP TIMER (WITH PDR)-
o The lap times recorded with the PDR system will
automatically be displayed in this window.
o This only happens if a track has been selected in the
PDR system and a video recording is started. See
(PDR) P- 131.
OIL TEMP- Shows the current oil temperature in either degrees
Celsius (°C) or degrees Fahrenheit (°F).
OIL PRESSURE- Shows the current oil pressure in either
kilopascal (kPa) or in pounds per square inch (psi).
BATTERY VOLTAGE- Shows the current battery voltage.
TRANSMISSION FLUID TEMP- Shows the temperature of the
transmission fluid in either degrees Celsius (°C) or degrees
Fahrenheit (°F).
TIRE STATUS-
Shows individual tire pressures and overall temperature as Cold,
Cool, Normal, Warm, Hot.
o Normal is typical for normal driving
o Warm is typical for aggressive driving.
o Unknown may be displayed if tire temperature
information is unavailable.
