9-52 Driving and Operating
Vehicle Axle Ratio Maximum Trailer Weight GCWR*
G1500 Cargo Van 2WD
4.3L V6 3.42 1 950 kg (4,300 lb) 4 309 kg (9,500 lb)
5.3L V8 3.42
3.73
3 039 kg (6,700 lb) 5 443 kg (12,000 lb)
H1500 Cargo Van AWD
5.3L V8 3.42 2 948 kg (6,500 lb) 5 443 kg (12,000 lb)
G1500 Passenger Van 2WD
5.3L V8 3.42
3.73
2 812 kg (6,200 lb) 5 443 kg (12,000 lb)
H1500 Passenger Van AWD
5.3L V8 3.42
3.73
2 722 kg (6,000 lb) 5 443 kg (12,000 lb)
G2500 Cargo Van 2WD Short Wheelbase
4.8L V8 3.42 3 357 kg (7,400 lb) 5 897 kg (13,000 lb)
6.0L V8 3.42 4 536 kg (10,000 lb) 7 257 kg (16,000 lb)
G2500 Cargo Van 2WD Long Wheelbase
4.8L V8 3.42 3 266 kg (7,200 lb) 5 897 kg (13,000 lb)
6.0L V8 3.42 4 536 kg (10,000 lb) 7 257 kg (16,000 lb)
