Technical Data 167
Vehicle Data
Main Engine Performance Parameters
Item Unit Parameter
Engine Model: L2B
LZW7156EJY
Parameter
Engine Model: LAR
LZW7156EJY
Transmission model: CTF25D Transmission model: CTF25D
Engine Type —
Four-stroke, water-cooled, in-line, 16-valve,
dual overhead camshaft, timing chain
drive, naturally aspirated, electronically
controlled gasoline injection and
electronically controlled ignition with DVCP
(double variable cam phase)
Four-stroke, water-cooled, in-line, 16-valve,
dual overhead camshaft, timing chain
drive, naturally aspirated, electronically
controlled gasoline injection and
electronically controlled ignition with DVCP
(double variable cam phase)
Cylinder Diameter × Travel mm×mm 74.7 × 84.7 74.7 × 84.7
Displacement L 1.485 1.485
Compression Ratio — 10.2:1 10.2:1
Rated Power/Speed kW/(r/min) 82/5800 73/5800
Maximum Net Power/Speed kW/(rpm) 78/5800 70/5800
Maximum Torque/Speed Nm/(rpm) 146.5/(3600–4000) 140/(3400-4400)
Gross Mass kg 106.5±2 101.5±2
Idle Speed rpm 750±50 750±50
Fuel type and grade — RON 92 and above motor gasoline RON 92 and above motor gasoline
