Turn Signal Lamps (Side)
Your vehicle may have this side turn signal lamp. To
replace this bulb, do the following:
1. Locate the bulb by reaching underneath the vehicle
where the side turn signal lamp is located.
2. Remove the side turn signal lamp assembly by
pulling it forward.
3. Turn the bulb socket counterclockwise.
4. Remove the bulb from the lamp housing by pulling
the bulb straight out of the socket.
5. Install the new bulb into the bulb socket by pushing
in and turning it clockwise.
6. Push the side turn signal lamp assembly back into
its original position.
Fog Lamps
To replace a fog lamp bulb, do the following:
1. Access the fog lamp bulb by reaching under the
front bumper.
2. Disconnect the wiring
harness connector
from the fog lamp
bulb socket.
3. Turn the bulb socket counterclockwise to remove it.
4. Install the new bulb.
5. Connect the wiring harness connector to the fog
lamp bulb socket.
5-40
