Chevrolet sonic 2017 - Engine Compartment Fuse

Chevrolet Sonic Owner Manual (GMNA-Localizing-U.S./Canada-10122660) -
2017 - crc - 5/13/16
Vehicle Care 243
Engine Compartment
Fuse Block
1.8L Engines
The engine compartment fuse block
is on the driver side of the vehicle,
near the battery.
Caution
Spilling liquid on any electrical
component on the vehicle may
damage it. Always keep the
covers on any electrical
component.
To access the fuses, press the clips
together, and lift the cover. To
reinstall the cover, push the cover
until it is secure.
The vehicle may not be equipped
with all of the fuses, relays, and
features shown.
Mini Fuses Usage
1 ABS valve
2 Sunroof
4* Rear fog lamp
5 OSRVM/Power
window switch
6 Automatic
occupant
sensing/ROS
7 Passive entry/
Passive start
8 RVC
10 –/IBS
11 Rear window
defogger
12 ESCL
13* –/SAI valve
14 OSRVM HTD
15 Front heated seats
16 Fuel system control
module 1
