117744 VVeehhiiccllee ccaarree
EEnnggiinnee aaiirr ffiilltteerr
11..55LL PPEETTRROOLL eennggiinnee
EElleemmeenntt cclleeaanniinngg::
1. Open the bonnet.
2. Loosen the screws.
3. Carefully pull the connector lock
AA towards you.
4. After the lock AA is disengaged,
push the lock AA together and pull
simultaneously the connector
outwards.
5. Loosen the metal clamp from the
hose.
6. Remove the hose.
7. Remove the air box cover
carefully.
8. Remove the air cleaner element
and clean it; slightly tap it.
9. Also clean the air cleaner inner
portion.
To Next Page
