VVeehhiiccllee ccaarree 118833
AApppplliiccaattiioonn PPoowweerr ((WW))
Front turn signal auxil‐
iary light
5
Rear turn signal light 21
Headlamp 5
Brake / Tail lamp - brake/
position
21
Front fog lamps 27
Rear fog lamp 21
Reverse gear 21
License 5
Load compartment 8
Passenger compart‐
ment
10
HHeeaaddlliigghhttss
LLooww bbeeaamm aanndd hhiigghh bbeeaamm
1. Detach the plug connector from
the bulb.
2. Remove the protective cover.
3. Press the spring clip and
disengage it.
4. Remove the bulb from the
reflector housing.
5. When fitting a new bulb, engage
the lugs in the recesses on the
reflector.
6. Engage the spring clip.
7. Place the headlight protective
cover in position and close.
Regard the correct position of the
protective cover.
8. Plug the connector onto bulb.
